Overview
Integrate YoLink smart devices by YoSmart with your Control4 system. YoLink uses long-range wireless technology, making it well-suited for large properties, outbuildings, and areas where standard smart home protocols fall short. Supports both cloud and local network connections.
- Cloud - Connects to the YoLink Cloud using the customer's account credentials. Works with any YoLink hub on the account.
- Local - Connects directly to a YoLink Local Hub on the LAN. No cloud dependency; one gateway instance per hub.
Features
- Real-Time Updates - Device state changes are pushed instantly with no polling delay
- Auto Setup - One-click action adds and binds the correct subdriver for every discovered device automatically
- Auto Rename - Subdrivers are automatically named to match the device name set in the YoLink app
- Auto-Reconnect - Automatic recovery from network disruptions and token expiration
- Multi-Region Support - Cloud mode is compatible with YoLink US and EU service zones
- Composer Programming - Variables, events, and commands for sensors, remotes, valves, and more
- Battery Status - Battery level is exposed as a property and programming variable on battery-powered devices
Device Compatibility
The following reflects current device support. Additional device types will be added in future updates or by request.
| Category | Supported |
|---|---|
| Dimmer Switches | ✅ |
| Door / Window / Contact Sensors | ✅ |
| Garage Door Sensors | ✅ |
| In-Wall Switches & Relays | ✅ |
| Motion Sensors | ✅ |
| Remotes & Fobs | ✅ |
| Smart Outlets & Plugs | ✅ |
| Smoke & CO Alarms | ✅ |
| Soil Temperature & Humidity Sensors | ✅ |
| Sprinkler Timer | ✅ |
| Temperature & Humidity Sensors | ✅ |
| Vibration Sensors | ✅ |
| Water Leak Sensors | ✅ |
| Water Valves & FlowSmart Controllers | ✅ |
| Garage Door Controls | ❌ |
| Multi-Outlet Power Strips | ❌ |
| Siren & Alarms | ❌ |
| Smart IR Remote | ❌ |
| Smart Locks | ❌ |
| Sprinkler Controller | ❌ |
| Thermostats | ❌ |
Note: Garage door sensors are supported as contact sensors (open/closed state). Garage door controllers (opener control) are not yet supported.
Requirements
- Control4 OS 3.3.0 or higher
- YoLink account with devices set up and online in the YoLink app
- YoLink Hub connected to the network (any model for cloud; Local Hub for local mode)
v20260826
- Add support for water valves and FlowSmart devices
- Add support for remotes and fobs (including short and long press programming events)
- Add programming variables on the sensor subdriver
- Add battery property and programming variable for battery-powered devices
v20260617
- Add support for smoke/CO alarm sensors
v20260611
- Initial release
